| Section | PK | PJ |
|---|---|---|
| H(mm) | 5.80 | 4.00 |
| h(mm) | 3.56 | 2.34 |
| p(mm) | 2.90 | 2.00 |
| Angle(o ) | 40 | 40 |
SIZE LIST
| Parts No. | Inched No. | Parts No. | Inched No. | Parts No. | Inched No. |
|---|---|---|---|---|---|
| 3PK 765 | 300 K3 | 5PK 735 | 290 K5 | 6PK 1245 | 490 K6 |
| 3PK 980 | 385 K3 | 5PK 800 | 315 K5 | 6PK 1255 | 495 K6 |
| 3PK 990 | 390 K3 | 5PK 825 | 325 K5 | 6PK 1270 | 500 K6 |
| 3PK 1055 | 415 K3 | 5PK 915 | 360 K5 | 6PK 1285 | 505 K6 |
| 4PK 605 | 238 K4 | 5PK 940 | 370 K5 | 6PK 1335 | 525 K6 |
| 4PK 630 | 240 K4 | 5PK 965 | 380 K5 | 6PK 1500 | 590 K6 |
| 4PK 700 | 275 K4 | 5PK 1015 | 400 K5 | 6PK 1510 | 595 K6 |
| 4PK 725 | 285 K4 | 5PK 1050 | 413 K5 | 7PK 940 | 370 K7 |
| 4PK 735 | 290 K4 | 5PK 1065 | 420 K5 | 7PK 990 | 390 K7 |
| 4PK 785 | 310 K4 | 5PK 1105 | 435 K5 | 8PK 760 | 300 K8 |
| 4PK 1015 | 400 K4 | 5PK 1120 | 440 K5 | 8PK 915 | 360 K8 |
| 4PK 1040 | 410 K4 | 5PK 1435 | 565 K5 | 8PK 925 | 365 K8 |
| 4PK 1080 | 425 K4 | 6PK 990 | 390 K6 | 8PK 940 | 370 K8 |
| 4PK 1195 | 470 K4 | 6PK 1015 | 400 K6 | 8PK 990 | 390 K8 |
| 4PK 1360 | 535 K4 | 6PK 1040 | 410 K6 | 8PK 1015 | 400 K8 |
| 4PK 1460 | 575 K4 | 6PK 1105 | 436 K6 | 8PK 1040 | 410 K8 |
| 4PK 1510 | 595 K4 | 6PK 1145 | 450 K6 | 8PK 1145 | 450 K8 |
| 5PK 695 | 273 K5 | 6PK 1155 | 455 K6 | 8PK 1245 | 490 K8 |
| 5PK 710 | 280 K5 | 6PK 1230 | 485 K6 | 8PK 1270 | 500 K8 |
