| Bearing No. | Bore | Outer Diameter | Width | Description of Specialties | |||||
|---|---|---|---|---|---|---|---|---|---|
| inch | mm | inch | mm | Outer Ring | Outer Ring | ||||
| inch | mm | inch | mm | ||||||
| 202NPP9 | 0.5050 | 12.827 | 1.5000 | 38.100 | 0.4331 | 11.000 | 0.4331 | 11.000 | O.D turned to 3/4 radius. Trash seals. |
| 202RRE | 0.5906 | 15.000 | 1.3780 | 35.000 | 0.4331 | 11.000 | 0.8800 | 22.352 | Special bore,extended inner ring. Trash seals |
| 203JD | 0.6693 | 17.000 | 1.5748 | 40.000 | 0.4724 | 12.000 | 0.5512 | 14.000 | Inner ring extended one side.Trash seals. |
| 203KR2 | 0.6253 | 15.883 | 1.5748 | 40.000 | 0.4724 | 12.000 | 0.5512 | 14.000 | |
| 203KRR2 | 0.6400 | 16.260 | 1.5748 | 40.000 | 0.4724 | 12.000 | 0.7200 | 18.288 | |
| 203KRR3 | 0.6280 | 15.951 | 2.0000 | 50.800 | 0.5906 | 15.000 | 0.5906 | 15.000 | Thick outer ring,two inch O.D.,Trash seals |
| 203KRR5 | 0.5150 | 13.081 | 1.5748 | 40.000 | 0.4720 | 12.000 | 0.7200 | 18.288 | |
| 203KRR6 | 0.6400 | 16.256 | 1.8504 | 47.000 | 0.4724 | 12.000 | 0.7200 | 18.288 | Thick outer ring,extended inner ring.Trash seals |
| 203KRR7 | 0.6693 | 17.000 | 1.5748 | 40.000 | 0.4720 | 12.000 | 0.6540 | 16.612 | |
| 203NPP9 | 0.6260 | 15.900 | 1.5748 | 40.000 | 0.5100 | 12.950 | 0.5100 | 12.950 | Special bore,special width. Trash seals |
| Z9504AB | 0.7500 | 19.050 | 1.7805 | 45.255 | 0.6100 | 15.494 | 0.6100 | 15.494 | |
| Z9504-2RST | 0.7500 | 19.050 | 1.7805 | 45.255 | 0.6100 | 15.494 | 0.6100 | 15.494 | Trash guarded seals.Fafnir 204RR6 |
| 204KR2 | 0.7505 | 19.063 | 1.7805 | 45.255 | 0.6100 | 15.494 | 0.6100 | 15.494 | |
| 204KRD4 | 0.6300 | 16.000 | 1.8504 | 47.000 | 0.5512 | 14.000 | 0.6890 | 17.500 | Special bore. Trash seals. |
| 204KRR3 | 0.7874 | 20.000 | 1.8504 | 47.000 | 0.5512 | 14.000 | 0.6890 | 17.755 | |
| 204KRR8 | 0.6260 | 15.900 | 1.7805 | 45.225 | |||||
| 204RR8 | 0.6310 | 16.027 | 1.7805 | 45.225 | 0.6100 | 15.494 | 0.6100 | 15.494 | Special bore,special O.D.,special width. Trash seals. |
| 204PY2 | 0.6310 | 16.027 | 1.7805 | 45.225 | 0.6100 | 15.494 | 0.7350 | 18.669 | Gothic arch race.Double lip trash seal extended side, |
| single lip trash seal opposite. | |||||||||
| 205E-2RST | 0.7560 | 19.202 | 2.0472 | 52.000 | 0.5906 | 15.000 | 0.8310 | 21.107 | Special bore,extended inner ring. Trash seals |
| 205KR3 | 0.7510 | 19.075 | 2.0472 | 52.000 | 0.7000 | 17.780 | 0.6400 | 16.256 | Special shroud seal one side only. |
| 205KR4 | 1.0005 | 25.413 | 2.0472 | 52.000 | 0.5906 | 15.000 | 1.0000 | 25.400 | |
| 205KP6 | 0.7560 | 19.202 | 2.0472 | 52.000 | 0.7000 | 17.780 | 0.9210 | 23.393 | Inner ring extended one side.inset side opposite. |
| Triple lip extended side,open side opposite. | |||||||||
| 205KRR6 | 0.5150 | 13.081 | 2.0472 | 52.000 | 0.5906 | 15.000 | 1.3750 | 34.925 | Special bore,extended inner ring. Trash seals |
| 205KRR7 | 0.5120 | 13.000 | 2.0472 | 52.000 | 0.5902 | 15.000 | 1.5000 | 38.100 | Inner ring extended both sides,bearing not centered |
| on inner ring. Trash seals. | |||||||||
| G205PPB7 | 0.9375 | 23.813 | 2.0472 | 52.000 | 0.5910 | 15.000 | 1.3780 | 35.000 | Same as 205PPB7 with grease groove. |
| 205PPB7 | 0.9375 | 23.813 | 2.0472 | 52.000 | 0.5910 | 15.000 | 1.3780 | 35.000 | Beveled O.D. Trash seals. |
| 205PP8 | 0.5140 | 12.964 | 2.0472 | 52.000 | 0.5910 | 15.000 | 1.3750 | 34.925 | Special bore, extended inner ring. Triple lip seals. |
| 205NPP9 | |||||||||
| 205PP9 | 0.7560 | 19.202 | 2.0472 | 52.000 | 0.5910 | 15.000 | 1.3750 | 34.925 | Special bore, extended inner ring. Triple lip seals. |
| 205PP10 | 0.6300 | 16.000 | 2.0472 | 52.000 | 0.5910 | 15.000 | 1.3750 | 34.925 | Special bore, extended inner ring. Triple lip seals. |
| 205PP12 | 0.6350 | 16.129 | 2.0472 | 52.000 | 0.5902 | 15.000 | 1.5000 | 38.100 | Inner ring extended both sides,bearing not centered |
| on inner ring. Trash seals. | |||||||||
| 206KR7 | 1.1811 | 30.000 | 2.4409 | 62.000 | 0.6300 | 16.000 | 0.9449 | 24.000 | |
| 206KRR6 | 1.0000 | 25.400 | 2.4409 | 62.000 | 0.9449 | ||||
| 206KRR8 | 1.1811 | 3..000 | 2.4409 | 62.000 | 0.6300 | 16.000 | 0.9449 | 24.000 | |
| 206KRRB | 0.7580 | 19.250 | 2.4409 | 62.000 | 0.6300 | 16.000 | 0.9449 | 24.000 | Special bore, extended inner ring. Triple lip seals. |
| 206KRRB6 | 1.000 | 25.400 | 2.4409 | 62.000 | 0.9449 | 24.000 | |||
| 206PD2 | 1.2500 | 31.750 | 2.5625 | 65.088 | 0.6693 | 17.000 | 0.7293 | 18.524 | Special O.D.,extended inner ring. Trash seals. |
| 207KYY | 1.3780 | 35.000 | 2.8346 | 72.000 | 0.6693 | 17.000 | 0.9843 | 25.000 | Extended inner ring.Double lip seal. |
| 99502H | 0.6250 | 15.875 | 1.3750 | 34.925 | 0.4331 | 11.000 | 0.4331 | 11.000 | |
| 499502H | 0.6250 | 15.875 | 1.3750 | 34.925 | 0.4331 | 11.000 | 0.4331 | 11.000 | With snap ring |
| 88128R | 1.5312 | 38.892 | 3.1496 | 80.000 | 0.8368 | 21.000 | 1.0830 | 27.500 | Bearing supplied with an axel ring. |
